Product Overview
Technical Specifications
Socket outlet |
|
| Model | Australian standard AS/NZS 3112 |
|---|---|
| Number of units | 1 |
| Number of socket outlets switchable | 1 |
| Imprint/indication | Without imprint |
| With hinged lid | Yes |
| Label space/information surface | No |
| Colour | White |
| With function lighting | No |
| With orientation lighting | No |
| Mounting method | Flush mounted (plaster) |
| Type of fastening | Mounting with screw |
| Nominal current | 15 |
|---|---|
| Nominal voltage | 250 V |
| Width of device | 42 |
| Height of device | 43 |
| Depth of device | 33 |
| Cover | Complete housing |
| Number of poles (total) | 2 |
| With label space | No |
| Assembly arrangement | Basic Mechanism |
| Drill hole distance centrically | 84 |
| Type of connection | Screwed terminal |
